HG Roller Scraper Dryer

HG Roller Scraper Dryer is an innovative solution for efficiently drying liquid or slurry-like materials in various industries such as food, chemical, pharmaceutical, and environmental protection. Its working principle involves forming a thin film of the material on the drum's surface, heated by water vapor or other heat carriers, and drying it during one revolution while being scraped off and re-exposed to the heat source for continuous drying. This dryer boasts several advantages, including high thermal efficiency due to heat transfer from the inner to outer wall of the cylinder, suitability for paste and viscous materials, and a new process for drying high-salt mother liquor wastewater. It features a large heating area, even heating, high drying rates, and short drying times (10 to 300 seconds), making it ideal for heat-sensitive materials and offering great operational flexibility. Additionally, the generated exhaust gas can be cooled, enhancing its practicality and environmental friendliness.

  • HG Roller Scraper Dryer
  • HG Roller Scraper Dryer
  • HG Roller Scraper Dryer
  • HG Roller Scraper Dryer
  • HG Roller Scraper Dryer

Parameter Spec. Φ800×1600 Φ1000×2000 Φ1200×2000 Φ1400×2400 Φ1600×2400
Heating Source Pressure(MPa) ≤0.6
Main Motor Power (kw) 3 4 4 5.5 7.5
Heating Transmission Area(m2) 4 6.2 7.5 10.5 12
Speed of the roller (rpm) 0.5~5
Heating Source Steam and Conducting oil
Feeding method Top or bottom

Who Are We?

Changzhou Yimin Drying Equipment Co., Ltd. is China HG Roller Scraper Dryer suppliers and OEM/ODM HG Roller Scraper Dryer company, located in the birthplace of China's drying equipment industry - Jiaoxi Industrial Park, Zhenglu Town, Changzhou City. It is adjacent to the Beijing-Shanghai Expressway, Shanghai-Nanjing Railway, and 5 kilometers from the Hengshan Crossing of the Shanghai-Nanjing Expressway. It is a key backbone enterprise in China's drying industry and pharmaceutical machinery. The company currently covers an area of ​​33,000 square meters and a building area of ​​18,000 square meters. The company has modern large-scale production workshops and equipment, fixed assets of more than 80 million yuan, and more than 120 employees. The founder of the company, Mr. Fan Yiming, has been committed to the research, production and operation of drying equipment for more than 20 years. At the same time, he has also brought together a group of high-quality talents integrating scientific research, design, production and service, and has long-term horizontal cooperation with relevant colleges and universities to continuously update and develop products.

At present, the company has more than 180 sets of processing equipment and strong technical force. It produces more than 2,000 sets of various drying, mixing, granulating, crushing, dust removal, powder screening and other equipment annually. The products have developed into eight series with more than 300 specifications and varieties, which are widely used in pharmaceutical, chemical, food, feed, mining, agricultural and sideline products, electronics, light industry and other industries. The products are distributed throughout the country and exported to the United States, Japan, Russia, Hong Kong, Taiwan and other places.

The factory also has a large test workshop with a full range of prototypes. Customers are welcome to bring materials for testing and ordering.
