ZLPG Herbal Extract Spray Dryer

The ZLPG Herbal Extract Spray Dryer represents a drying technology tailored specifically for traditional Chinese medicine extracts. Developed by integrating foreign expertise, this equipment addresses the challenges posed by low melting points and high sugar content in such extracts. Its advanced design meticulously determines drying conditions, ensuring product quality and adherence to GMP standards. Featuring high automation and user-friendly operation, it resolves longstanding technical hurdles that hinder effective spray drying in traditional Chinese medicine production. Utilizing centrifugal spray drying technology, it disperses materials finely for rapid drying, yielding powdery finished products. Key features include anti-wall sticking mechanisms, efficient product-air separation, and advanced air purification, all contributing to enhanced yield and purity. With options for customization and adherence to GMP specifications, this dryer stands as a groundbreaking innovation in traditional Chinese medicine pharmaceutical processing.

  • ZLPG Herbal Extract Spray Dryer
  • ZLPG Herbal Extract Spray Dryer
  • ZLPG Herbal Extract Spray Dryer
  • ZLPG Herbal Extract Spray Dryer

Type ZLPG-5 ZLPG-10 ZLPG-25 ZLPG-50 ZLPG-80 ZLPG-100 ZLPG-150 ZLPG-200 ZLPG-300
Evaporated amount of moisture kg/h 5 10 25 50 80 100 150 200 300
Treated amount of raw material liquid(kg/h) 45450 45640 25-34 50-68 80-108 100-135 150-203 200-270 300-406
Output of finished product(kg/h) 45293 45326 4.8-7.2 9.2-14 14.8-22.4 18.4-28 28-42 36.8-56.4 55-85
Solid content of raw material (%) 18-25
Ratio of moisture of finished product (%) 45356
Electric power(kw) 36 45 63 99 132 153 204 246 330
Heating source Steam plus electricity
Collecting way of product and its efficiency Two-grad cyclone or grade cyclone duster and one-grade damp duster ≥95%
Automatic control Indicator of temperature of hot air and humidity of air exhaust
Temperature of air in (℃) 150-200
Temperature of air out (℃) 80-100
Overall dimensions (mm) L 5000 5500 7000 8000 9800 11000 12200 14100 15000
W 3000 3500 4000 5000 5700 6200 7000 7800 9000
H 4500 4600 5200 6500 7600 8100 9000 9850 11100
