FL One-step Fluid Bed Granulator

The FL One-step Fluid Bed Granulator, a versatile solution tailored for the pharmaceutical, food, chemical, and other industries. This innovative machine seamlessly integrates mixing, drying, granulating, and top-spray coating functionalities, offering a comprehensive one-step granulation process. Ideal for pharmaceutical applications, it efficiently handles tablet granules, capsule granules, and coatings including protective layers, sustained release formulations, and enteric coatings. In the food sector, it excels at granulating and coating various products such as sugar, coffee, powdered juice, and seasonings, enhancing their properties and quality. Additionally, it accommodates pesticides, pigments, and dye granulation needs. Key features include anti-static filter technology ensuring safe operation, a pressure relief hole to mitigate potential risks, and a design free of dead corners for easy material handling and compliance with GMP requirements.

  • FL One-step Fluid Bed Granulator
  • FL One-step Fluid Bed Granulator
  • FL One-step Fluid Bed Granulator
  • FL One-step Fluid Bed Granulator
  • FL One-step Fluid Bed Granulator
  • FL One-step Fluid Bed Granulator
  • FL One-step Fluid Bed Granulator
  • FL One-step Fluid Bed Granulator

Item Unit Type
3 5 15 30 60 120 200 300 500
container volume L 12 22 45 100 220 420 670 1000 1500
diameter mm 300 400 550 700 1000 1200 1400 1600 1800
capability min. kg 1.5 4 10 15 30 80 100 150 250
max. kg 4.5 6 18 36 72 140 240 360 600
fan capacity m3/h 1000 1200 1400 1800 3000 4500 6000 7000 8000
pressure mm H2O 375 375 480 480 950 950 950 950 950
power kW 3 4 5.5 7.5 11 18.5 22 30 37
steam expenditure kg/h 15 23 42 70 141 211 282 366 451
compressed air expenditure m3/min 90 0.6 90 0.9 0.9 0.9 1.1 1.5 1.5
weight of the main body kg 250 300 700 900 1100 1300 1500 1800 2000
steam pressure MPa 0.3-0.6
temperature adjustable at the range from room temperature to 120℃
working time min decided in accordance with the properties of raw materials
field % 2.99
noise dB(A) When installation, main machine is separated from fan
size m 1.0x 0.55x1.8 1.2x0.6x2.1 1.25x0.75x2.1 1.6x0.9x2.3 1.85x1.25x3 2.2x 1.65x3.3 2.34x1.7x3.8 2.8x1.9x3.8 3x2.25x4.2

Who Are We?

Changzhou Yimin Drying Equipment Co., Ltd. is China FL One-step Fluid Bed Granulator suppliers and OEM/ODM FL One-step Fluid Bed Granulator company, located in the birthplace of China's drying equipment industry - Jiaoxi Industrial Park, Zhenglu Town, Changzhou City. It is adjacent to the Beijing-Shanghai Expressway, Shanghai-Nanjing Railway, and 5 kilometers from the Hengshan Crossing of the Shanghai-Nanjing Expressway. It is a key backbone enterprise in China's drying industry and pharmaceutical machinery. The company currently covers an area of ​​33,000 square meters and a building area of ​​18,000 square meters. The company has modern large-scale production workshops and equipment, fixed assets of more than 80 million yuan, and more than 120 employees. The founder of the company, Mr. Fan Yiming, has been committed to the research, production and operation of drying equipment for more than 20 years. At the same time, he has also brought together a group of high-quality talents integrating scientific research, design, production and service, and has long-term horizontal cooperation with relevant colleges and universities to continuously update and develop products.

At present, the company has more than 180 sets of processing equipment and strong technical force. It produces more than 2,000 sets of various drying, mixing, granulating, crushing, dust removal, powder screening and other equipment annually. The products have developed into eight series with more than 300 specifications and varieties, which are widely used in pharmaceutical, chemical, food, feed, mining, agricultural and sideline products, electronics, light industry and other industries. The products are distributed throughout the country and exported to the United States, Japan, Russia, Hong Kong, Taiwan and other places.

The factory also has a large test workshop with a full range of prototypes. Customers are welcome to bring materials for testing and ordering.
